Norco Revolver HT XTR 100

Norco Revolver HT XTR 100
Red Fade
Please select options
Sorry, this item is currently not available. Please call to see if there is another item we could suggest.


Modern cross country mountain bike racing has changed, so we re-designed and optimized the Norco Revolver HT to carry cross country racers to the top of the podium.

The rider-centered design makes the most of every pedal stroke, while the precise engineering of the lightweight, efficient frame will transmit every Watt you produce into conquering today’s physically demanding XC courses. The World Cup caliber RockShox SID Ultimate 100mm fork soaks up the bumps, and the Crank Bros. Highline dropper gets the saddle out of the way when the going gets rough.

Featuring Shimano’s new 12-speed XTR group, the Revolver HT XTR is as fast and as light as an XC hardtail can get. With XTR race brakes, DT Swiss 350/Stans Arch S1 tubeless ready wheels and Schwalbe Racing Ray 29x2.25” tires, you’ll be out of excuses for not riding your best this year.

- Carbon XC Race frame
- RockShox SID Ultimate 100mm fork
- Shimano XTR 12-speed drivetrain w/Race Face Next SL Carbon crankset
- Stans Arch S1 rims w/DT 350 hubs
- Shimano XTR hydraulic disc brakes

A dropper seatpost allows you to quickly lower and raise your seat to give you an ideal riding position. Dropping your seat creates a lower center of gravity for better control and maneuverability on steep descents, while raising it puts you at normal riding height for efficient pedaling.

Construction can include either hydraulic- or cable-actuated systems and the post’s travel can either be infinitely adjustable or stopped at set intervals, depending on the model.

Dropper seatposts come in standard lengths and diameters and vary by the amount of travel.


Frame Carbon XC Race
Fork RockShox SID Ultimate, 100mm Travel
Headset FSA Internal Headset
Axles Front: 15 x 110mm Boost thru-axle
Rear: 12 x 148mm Boost thru-axle
Rims/Wheels Stans Arch S1 29"
Hubs DT Swiss 350
Spokes Sapim Sprint DB
Tires Schwalbe Racing Ray 29x2.25", Snakeskin Addix Speedgrip
Crankset Race Face Next SL Carbon
Chainrings 32T
Bottom Bracket Race Face BB92, Double Row
Chain Shimano XTR M9100
Rear Derailleur Shimano XTR M9120
Cassette/Rear Cogs Shimano XTR M9100, 10-51T
Shifters Shimano XTR M9100, 12 speed, I-Spec EV
Handlebars Race Face Next R Carbon, 780mm, 20mm rise
Tape/Grips SRAM Twistloc
Stem 6061 Alloy, 60mm, 35mm bore
Brakes Shimano XTR M9120 Hydraulic,180mm front / 160mm rear rotors
Saddle Fizik Taiga
Seat Post Crank Bros. Highline 3, 31.6mm

* Subject to change without notice.

Part Numbers

Option UPC MPN
Red Fade / Small 058817428043 0665110904
Red Fade / Medium 058817428050 0665110905
Red Fade / Large 058817428067 0665110906
Red Fade / X-Large 058817428081 0665110907
