All-day performance and breakneck speed on every trail. The Revolver 2 FS 120 brings all the features of our new endurance race machines to a wide array of riders, with SRAM's NX Eagle group and a parts spec designed for low weight, durability, and superb handling on every high-speed adventure. The stiff carbon frame makes the most of every pedal stroke, while the precision-tuned kinematics combine with the RockShox SID Select and Deluxe Select+ suspension package to provide all-day comfort and control.
- Full Carbon 120mm Frame, Updated Geometry with Gravity Tune
- Rock Shox Sid Select 120mm Boost Fork
- Rock Shox Deluxe Select + 190 x 45 Metric Rear Shock
- SRAM NX Eagle 12-speed Drivetrain
- Crank Bros. Highline 3 Dropper Post
A dropper seatpost allows you to quickly lower and raise your seat to give you an ideal riding position. Dropping your seat creates a lower center of gravity for better control and maneuverability on steep descents, while raising it puts you at normal riding height for efficient pedaling.
Construction can include either hydraulic- or cable-actuated systems and the post’s travel can either be infinitely adjustable or stopped at set intervals, depending on the model.
Dropper seatposts come in standard lengths and diameters and vary by the amount of travel.
Pedals sold separately
|Frame||Hi-Mod Carbon, 120mm Rear Travel|
|Fork||Rock Shox Sid Select, 120mm Travel, Boost|
|Rear Shock||Rockshox Deluxe Select+ RL|
Front: 15 x 110mm Boost thru-axle
Rear: 12 x 148mm Boost thru-axle
|Rims/Wheels||Stans Arch D, 29"|
Rear: DT Swiss 370
|Spokes||Sapim Sprint DB|
|Tires||Maxxis Forekaster, 29 x 2.35"|
|Crankset||SRAM NX Eagle DUB|
|Bottom Bracket||SRAM DUB, Press Fit, 92mm|
|Chain||SRAM NX Eagle, 12 speed|
|Rear Derailleur||SRAM NX Eagle, 12 speed|
|Cassette/Rear Cogs||SRAM PG1230 Eagle, 11-50T|
|Shifters||SRAM NX Eagle 12 speed, MMX|
|Handlebars||6061 DB Aluminum, 31.8mm, 760mm Length, 15mm Rise|
|Tape/Grips||Ergon GA30, Lock-on|
|Stem||SL Aluminum, 60mm Length|
Front: SRAM Guide T, 180mm
Rear: SRAM Guide T, 160mm
|Seat Post||Crank Bros. Highline 3, 31.6mm|
* Subject to change without notice.
|Carbon/Concrete / Small||058817407642||0660610944|
|Carbon/Concrete / Medium||058817407659||0660610945|
|Carbon/Concrete / Large||058817407666||0660610946|
|Carbon/Concrete / X-Large||058817407673||0660610947|
